Features: • 30 ISO bands with +/-15dB of gain each • Center-detent filter bypass at 0dB for maximum performance • Custom finger-fit fader knobs • Hi and lo shelving contour controls for sweetening • Constant Q filters for better efficiency • 8-segment LED input/output metering with a CLIP indicator • Balanced inputs and outputs on XLR, 1/4-inch jack, and screw terminal connectors Specifications: Input Section: • Input Impedance: 10kOhm, electronically balanced • Maximum Input Level: >+20dBu • CMRR: >-40dB @ 1kHz Output Section: • Output Impedance: < 50 Ohms, electronically balanced • Maximum Output Level: >+20dBu into 600 Ohms Filters: • HP filter control: OUT to 250Hz @ 12dB/octave • LF contour: +/-6dB shelving @ 50Hz 6dB/octave • HF contour: +/-6dB shelving @ 14kHz 6dB/octave Frequency Bands: • +/-15dB on ISO centers with a Q of 4 Additional Specifications: • Frequency Response: 5Hz to 45kHz +/-1dB • Noise: <-94dBu 22Hz to 22kHz • Dynamic Range: > 115dB • Cross Talk: >-80dB @ 1kHz • Distortion: <0.005% THD (80kHz measurement BW) 20Hz-20kHz • GAIN control: +10dB to -infinity Dimensions & Weight: • Dimensions: 19" x 5.25" x 7.1" (483mm x 134mm x 180mm) • Weight: 6.6lbs (3kgs), unpacked Power: • AC Power: 115/230V AC, 50/60Hz, 30VA
DELIVERY CHARGE EXTRA***
